2POTS
Technical drawing2POTS
Description
Two-pot pre-wired harness linked by black insulated wire, with trailing leads for pickup and output connections.
Wiring harness specs
- Potentiometer count 2
- Layout reference No fixed mounting plate; spacing between the two pots is adjustable via interconnecting wire length.
Hardware
- Material Potentiometers and wire harness (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Split-knurled shafts with long threaded bushings on both pots
- Small tone capacitor on one pot; stripped wire ends at harness tails
About measurements
- Mount hole spacing
-
No fixed mounting plate; spacing between the two pots is adjustable via interconnecting wire length.
Center-to-center distance between mounting holes on the bridge plate.
