BANJO PARTS
Request a quote → BJ-215
BJ-215
BJ-215
Loading 3D model…
Loading 3D model…
Description
Coordinator spring bar with 84.4 mm rod, Φ9 mm head (32 mm tall) and Φ5 mm tip.
Banjo hardware specs
- Outer diameter φ9 mm
- Overall length 84.4 mm (3.323 in)
- Body height 32 mm (1.26 in)
- Hole diameter φ5 mm
- Reference Coil section width 6.1 mm
Hardware
- Material Zinc alloy / steel (per part)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Coiled spring section for tension adjustment
- Φ9 mm cylindrical head
- Φ5 mm tapered tip
About measurements
- Mount hole spacing
-
Coil section width 6.1 mm
Center-to-center distance between mounting holes on the bridge plate.
