BANJO PARTS
Request a quote → BJ-240
BJ-240
BJ-240
Loading 3D model…
Loading 3D model…
Description
Double-threaded banjo rod 150 mm overall with M8 nut section (52 mm) and M6 opposite end.
Banjo hardware specs
- Overall length 150 mm (5.906 in)
- Shank length 52 mm (2.047 in)
- Thread M8 × M6 double-ended
- Reference M8 nut section 52 mm; M6 internal thread at opposite end
Hardware
- Material Zinc alloy / steel (per part)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- M8 / M6 double-ended rod
- 52 mm nut engagement section
About measurements
- Mount hole spacing
-
M8 nut section 52 mm; M6 internal thread at opposite end
Center-to-center distance between mounting holes on the bridge plate.
