HC-3223
HC-3223
Loading 3D model…
Loading 3D model…
Description
HC-3223 control plate, 77 × 42 mm stadium plate, φ2.5 mm 2-hole mount.
Control plate specs
- Overall width 77 mm (3.031 in)
- Overall length 42 mm (1.654 in)
- Hole diameter φ2.5 mm
- Mount spacing 70.09 mm (2.759 in)
- Reference Two end holes on 70.09 mm centers; countersink φ5 mm.
Hardware
- Material Plastic plate (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Stadium outline 77 mm × 42 mm
- Two countersunk φ2.5 mm holes on 70.09 mm centers
About measurements
- Mount hole spacing
-
70.09 mm (2.759 in)
Center-to-center distance between mounting holes on the bridge plate.
