Description
L-2001 is a flat string-retainer sleeve bar 83 mm long × 16 mm wide with six holes at 10.5 mm pitch.
Bushing / sleeve specs
- Outer diameter φ16 mm
- Body height 16 mm (0.63 in)
- Overall height 83 mm (3.268 in)
- Reference Six holes at 10.5 mm pitch spanning 52.5 mm; end mounting holes (diameter not dimensioned on drawing).
Hardware
- Material Brass / steel / plastic (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Elongated bar 83 mm × 16 mm with rounded ends
- Six evenly spaced holes at 10.5 mm pitch
About measurements
- Mount hole spacing
-
Six holes at 10.5 mm pitch spanning 52.5 mm; end mounting holes (diameter not dimensioned on drawing).
Center-to-center distance between mounting holes on the bridge plate.
