Guitar Pickups
Request a quote → P-1009
P-1009
P-1009
Loading 3D model…
Loading 3D model…
Description
Soapbar pickup with 85.5 mm overall length, 34.5 mm body width, and 20 mm mount spacing.
Pickup specs
- String count 6-string
- Overall width 34.5 mm (1.358 in)
- Overall length 85.5 mm (3.366 in)
- Mount spacing 20 mm (0.787 in)
- Reference Pole spacing 50-52 mm.
Hardware
- Material Alnico / ceramic magnets; metal cover or bobbin (per model)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Six screw-type pole pieces in a single row
- Rectangular body with rounded corners and internal mounting holes between poles
About measurements
- Mount hole spacing
-
20 mm (0.787 in)
Center-to-center distance between mounting holes on the bridge plate.
