P-3010N
Technical drawingP-3010N
Description
4-string pickup, 61.2 mm plate width, 54.5 mm mount spacing.
Pickup specs
- String count 4-string
- Overall width 13.1 mm (0.516 in)
- Overall length 61.2 mm (2.409 in)
- Mount spacing 54.5 mm (2.146 in)
- Reference Center-to-center between wing mounting holes.
Hardware
- Material Alnico / ceramic magnets; metal cover or bobbin (per model)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Four pole pieces, outer spacing 32.5 mm
- Rounded rectangular coil area 45.5 × 13.1 mm
About measurements
- Mount hole spacing
-
54.5 mm (2.146 in)
Center-to-center distance between mounting holes on the bridge plate.
