TH-007
Technical drawingTH-007
Description
TH-007 mandolin pickguard, 151.6 × 138.4 mm L-shaped plate with pickup slot and φ3.2 mm mounting holes on 69 mm centers.
Pickguard specs
- Overall width 151.6 mm (5.969 in)
- Overall length 138.4 mm (5.449 in)
- Mount hole diameter φ3.2 mm
- Mount spacing 69 mm (2.717 in)
- Layout reference Pickup-slot flanking holes on 69 mm centers; additional φ3.2 mm perimeter holes (spacing not dimensioned on drawing).
Hardware
- Material PVC / ABS plastic (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- L-shaped outline 151.6 mm × 138.4 mm with horizontal pickup arm
- Pickup slot cutout 20 mm high; slot-flanking holes on 69 mm centers
About measurements
- Mount hole spacing
-
69 mm (2.717 in)
Center-to-center distance between mounting holes on the bridge plate.
