BG-5001
BG-5001
Loading 3D model…
Loading 3D model…
Description
BG-5001 is a vintage 3-saddle Tele bridge plate with slanted pickup rout, 10.5 mm string spacing (52.5 mm spread), and φ8 mm barrel saddles on an 85.5 × 76.6 mm plate.
Bridge specs
- String count 6-string
- String spacing 10.5 mm (0.413 in)
- String spread 52.5 mm (2.067 in)
- Plate width 85.5 mm (3.366 in)
- Plate depth 76.6 mm (3.016 in)
- Mount pattern Pickup holes 44 mm; cutout 70.5 × 20.4 mm
- Saddle material Steel
- Saddle diameter 8 mm (0.315 in)
- Saddle height 21 mm (0.827 in)
Hardware
- Adjustment Height and intonation screws
- Finish More colors — see matching swatches
Features
- 3-barrel saddle Tele plate
- Slanted single-coil rout
About measurements
- String spacing
-
10.5 mm (0.413 in)
Center-to-center distance between adjacent strings at the bridge.
- Mount hole spacing
-
Pickup holes 44 mm; cutout 70.5 × 20.4 mm
Center-to-center distance between mounting holes on the bridge plate.
