BANJO PARTS
Request a quote → BJ-245
BJ-245
BJ-245
Loading 3D model…
Loading 3D model…
Description
5-string banjo string retainer 32.3 × 20.7 × 20.7 mm with Φ4.5 mm holes on 23.4 mm pitch.
Banjo hardware specs
- String count 5-string
- Overall width 23.4 mm (0.921 in)
- Overall length 32.3 mm (1.272 in)
- Body height 20.7 mm (0.815 in)
- Hole diameter φ4.5 mm
- Reference Body depth 20.7 mm; five string holes on 23.4 mm pitch
Hardware
- Material Zinc alloy / steel (per part)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Five-hole string retainer block
- Wider pitch for 5-string spacing
About measurements
- Mount hole spacing
-
Body depth 20.7 mm; five string holes on 23.4 mm pitch
Center-to-center distance between mounting holes on the bridge plate.
