Description
F-1006 is an output jack plate, 59.6 × 31.7 mm recessed oval with φ10 mm jack hole and two φ4.2 mm mounting holes.
Output jack plate specs
- Overall width 59.6 mm (2.346 in)
- Overall length 31.7 mm (1.248 in)
- Hole diameter φ10 mm
- Reference Two φ4.2 mm mounting holes (center-to-center spacing not dimensioned on drawing).
Hardware
- Material Plastic / metal (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Recessed oval 59.6 mm × 31.7 mm plate
- Central φ10 mm jack hole with two end mounting holes
About measurements
- Mount hole spacing
-
Two φ4.2 mm mounting holes (center-to-center spacing not dimensioned on drawing).
Center-to-center distance between mounting holes on the bridge plate.
