Jack Plates
Request a quote → F-1007
F-1007
F-1007
Loading 3D model…
Loading 3D model…
Description
F-1007 is an output jack plate, 16.6 mm wide with φ10 mm jack hole and 44.5 mm hole spacing.
Output jack plate specs
- Overall length 16.6 mm (0.654 in)
- Hole diameter φ10 mm
- Mount spacing 44.5 mm (1.752 in)
- Reference φ10 mm jack hole and φ8 mm hole, 44.5 mm center-to-center.
Hardware
- Material Plastic / metal (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Narrow oval plate, 16.6 mm wide
- Recessed trapezoidal well around φ10 mm jack hole
About measurements
- Mount hole spacing
-
44.5 mm (1.752 in)
Center-to-center distance between mounting holes on the bridge plate.
