Truss rod cover
Request a quote → HA-2011
HA-2011
Technical drawingHA-2011
Description
HA-2011 truss rod cover, 45.6 × 30 mm bell profile with concave top, φ3 mm 3-hole mount.
Headstock plate specs
- Overall width 30 mm (1.181 in)
- Bottom width 30 mm (1.181 in)
- Overall length 45.6 mm (1.795 in)
- Hole diameter φ3 mm
- Mount spacing 20 mm (0.787 in)
- Reference Bottom hole pair on 20 mm centers; top hole center 36.7 mm from bottom edge.
Hardware
- Material Plastic plate (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Bell profile 45.6 mm tall × 30 mm base, 11.9 mm concave top width
- φ3 mm holes on 20 mm / 36.7 mm 3-hole layout
About measurements
- Mount hole spacing
-
20 mm (0.787 in)
Center-to-center distance between mounting holes on the bridge plate.
