Description
KA-1002 threaded barrel jack M12 × 0.75 with φ16 mm bezel, φ11.5 mm opening, 48 mm overall length.
Output jack specs
- Outer diameter φ16 mm
- Inner diameter φ11.5 mm
- Overall length 48 mm (1.89 in)
- Body height 39 mm (1.535 in)
- Thread M12 × 0.75
- Reference Threaded barrel 36.1 mm; two solder terminals.
Hardware
- Material Brass / nickel-plated steel (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- M12 × 0.75 threaded barrel
- φ11.5 mm plug opening
About measurements
- Mount hole spacing
-
Threaded barrel 36.1 mm; two solder terminals.
Center-to-center distance between mounting holes on the bridge plate.
