GUITAR MACHINE HEADS
Request a quote → M-1A01S
M-1A01S
M-1A01S
Loading 3D model…
Loading 3D model…
Description
M-1A01SH is an integrated gear-shaft locking tuner with a small square head button and a top cylindrical knurled locking cap.
Tuning machine specs
- Mount style Integrated rivet-press installation
Hardware
- Material Zinc alloy
- Adjustment Tuning adjustment
- Finish More colors — see matching swatches
Features
- Integrated gear shaft
- Adjustable string hole height
About measurements
- Mount hole spacing
-
Product photo only (M-1A01SH.png); no dimensioned drawing in dim-cache.
Distance from the locating pin at the bottom of the tuner housing to the shaft center.
Gear ratio options
Standard ratio 21:1
Economy ratio 18:1
Contact us to confirm the ratio supplied for your model and configuration.
