M-4270
Technical drawingM-4270
Description
M-4270 is a open-gear machine head with φ6 mm post, 20.8 mm post length, φ10 mm headstock bore.
Tuning machine specs
- Post diameter φ6 mm
- Post length 20.8 mm (0.819 in)
- Housing width 14.5 mm (0.571 in)
- Housing depth 29.6 mm (1.165 in)
- Housing height 9.7 mm (0.382 in)
- Bushing height 13 mm (0.512 in)
- Bushing outer diameter φ10 mm
- Mount style Two-screw plate mount
Hardware
- Material Zinc alloy
- Adjustment Tuning adjustment
- Finish More colors — see matching swatches
Features
- Open-gear machine head
- Two-screw plate mount
About measurements
- Post diameter
-
6 mm (0.236 in)
Diameter of the string post where the string is wound.
Configurations
Gear ratio
ratio-1
