MB-3639

BASS MACHINE HEADS

MB-3639

MB-3639

Request a quote →

MB-3639

Description

MB-3639 is a bass machine head with φ13 mm post, 24.6 mm post length, φ15.2 mm headstock bore.

Tuning machine specs

Post diameter φ13 mm
Post length 24.6 mm (0.969 in)
Headstock bore φ15.2 mm
Housing width 34 mm (1.339 in)
Housing depth 43 mm (1.693 in)
Housing height 14 mm (0.551 in)
Bushing height 14 mm (0.551 in)
Washer outer diameter φ19 mm
Mount style Two-screw plate with M13×1 threaded bushing

Hardware

Material Zinc alloy
Adjustment Tuning adjustment
Finish More colors — see matching swatches

Features

Open-gear bass machine head
Two-screw plate mount
Slotted post
M13×1 threaded bushing with hex nut

About measurements

Post diameter

13 mm (0.512 in)

Diameter of the string post where the string is wound.

Headstock bore

15.2 mm (0.598 in)

Recommended headstock hole diameter for the tuner collar.

Configurations
