Description
P-2009 is a dual-blade humbucker pickup with a 69 × 37 mm body and 77.5 mm mount spacing.
Pickup specs
- String count 6-string
- Overall width 37 mm (1.457 in)
- Overall length 84 mm (3.307 in)
- Mount spacing 77.5 mm (3.051 in)
- Reference Overall width including tabs 84 mm; blade length 64 mm
Hardware
- Material Alnico / ceramic magnets; metal cover or bobbin (per model)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Dual-coil humbucker with rail-style blade pole pieces
- Side mounting tabs with one hole each
- Blade pole length 64 mm
About measurements
- Mount hole spacing
-
77.5 mm (3.051 in)
Center-to-center distance between mounting holes on the bridge plate.
