Bass Pickups
Request a quote → PB-1002
PB-1002
PB-1002
Loading 3D model…
Loading 3D model…
Description
PB-1002 4-string pickup, 57.5 × 28.2 mm body, 72 mm overall width, 65 mm mount spacing.
Pickup specs
- String count 4-string
- Overall width 28.2 mm (1.11 in)
- Overall length 57.5 mm (2.264 in)
- Mount spacing 65 mm (2.559 in)
- Reference Total width including ears 72 mm; four pole pieces in one row.
Hardware
- Material Alnico / ceramic magnets; metal cover or bobbin (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
About measurements
- Mount hole spacing
-
65 mm (2.559 in)
Center-to-center distance between mounting holes on the bridge plate.
