Description
Oblong pickup plate, 70 × 17.7 mm, three-point mount.
Pickup specs
- Overall width 17.7 mm (0.697 in)
- Overall length 70 mm (2.756 in)
- Mount spacing 46 mm (1.811 in)
- Reference Bottom mount holes 46 mm c-c; top hole 27.3 mm from bottom pair.
Hardware
- Material Alnico / ceramic magnets; metal cover or bobbin (per model)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Three mounting tabs: one top center, two bottom
About measurements
- Mount hole spacing
-
46 mm (1.811 in)
Center-to-center distance between mounting holes on the bridge plate.
