Bass Pickups
Request a quote → P-KD40
P-KD40
P-KD40
Loading 3D model…
Loading 3D model…
Description
Rectangular pickup plate, 70.3 × 38 mm, three-point mount.
Pickup specs
- Overall width 38 mm (1.496 in)
- Overall length 70.3 mm (2.768 in)
- Mount spacing 46 mm (1.811 in)
- Reference Bottom mount holes 46 mm c-c; overall height 47.6 mm.
Hardware
- Material Alnico / ceramic magnets; metal cover or bobbin (per model)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Three mounting tabs: one top center, two bottom
- Rounded corners
About measurements
- Mount hole spacing
-
46 mm (1.811 in)
Center-to-center distance between mounting holes on the bridge plate.
