Description
BA-1014 is a 5-string bass bridge with steel saddles, 17.5 mm string spacing, and an 80.3 × 53.2 mm plate.
Bridge specs
- String count 5-string
- String spacing 17.5 mm (0.689 in)
- Plate width 80.3 mm (3.161 in)
- Plate depth 53.2 mm (2.094 in)
- Mount hole spacing 70 mm (2.756 in)
- Mount pattern 5 holes on 17.5 mm pitch (outer centers 70 mm)
- Saddle material Steel
- Saddle diameter 18.8 mm (0.74 in)
- Hole diameter φ9 mm (0.354 in)
Hardware
- Adjustment Height and intonation screws
- Finish More colors — see matching swatches
Features
- 5-string layout
- 17.5 mm tighter spacing
- Five-hole top mount
About measurements
- String spacing
-
17.5 mm (0.689 in)
Center-to-center distance between adjacent strings at the bridge.
- Mount hole spacing
-
70 mm (2.756 in)
Center-to-center distance between mounting holes on the bridge plate.
