Bass Bridges
Request a quote → BA-1016
BA-1016
BA-1016
Loading 3D model…
Loading 3D model…
Description
BA-1016 is a 4-string bass bridge with zinc saddles, 82 × 52 mm footprint, and four-corner mount on 68 × 36 mm centers.
Bridge specs
- String count 4-string
- String spacing 17.8 mm (0.701 in)
- Plate width 82 mm (3.228 in)
- Plate depth 52 mm (2.047 in)
- Mount hole spacing 68 mm (2.677 in)
- Mount pattern Corner holes 68 mm wide × 36 mm deep
- Saddle material Zinc alloy
- Saddle diameter 17.8 mm (0.701 in)
- Saddle height 9.5 mm (0.374 in)
Hardware
- Adjustment Height and intonation screws
- Finish More colors — see matching swatches
Features
- Four-corner mount
- Teardrop string slots
About measurements
- String spacing
-
17.8 mm (0.701 in)
Center-to-center distance between adjacent strings at the bridge.
- Mount hole spacing
-
68 mm (2.677 in)
Center-to-center distance between mounting holes on the bridge plate.
