BATTERY COMPARTMENT
Request a quote → BC-03
BC-03
Technical drawingBC-03
Description
BC-03 is a small battery housing insert, 43.1 × 18.2 mm flange with 35.1 mm recessed body width and 16.1 mm overall height.
Battery box specs
- Flange width 43.1 mm (1.697 in)
- Flange depth 18.2 mm (0.717 in)
- Cavity width 35.1 mm (1.382 in)
- Overall height 16.1 mm (0.634 in)
Hardware
- Material Plastic housing
- Adjustment N/A
- Finish Black plastic (standard)
Features
- Compact insert for tight control cavities
- 14.3 mm main body height
