Truss rod cover
Request a quote → HA-1001
HA-1001
HA-1001
Loading 3D model…
Loading 3D model…
Description
HA-1001 truss rod cover, 43.5 mm long, 31.5 mm wide end / 10 mm tip, φ2.6 mm 3-hole mount.
Headstock plate specs
- Overall width 31.5 mm (1.24 in)
- Bottom width 31.5 mm (1.24 in)
- Overall length 43.5 mm (1.713 in)
- Hole diameter φ2.6 mm
- Mount spacing 20 mm (0.787 in)
- Reference Wide-end hole pair on 20 mm centers; tip hole center 34.5 mm from base hole axis.
Hardware
- Material Plastic plate (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Trapezoidal outline 31.5 mm wide end tapering to 10 mm tip
- Countersunk φ2.6 mm holes on 20 mm / 34.5 mm 3-hole layout
About measurements
- Mount hole spacing
-
20 mm (0.787 in)
Center-to-center distance between mounting holes on the bridge plate.
