Truss rod cover
Request a quote → HA-1002
HA-1002
Technical drawingHA-1002
Description
HA-1002 truss rod cover, 46.8 × 32 mm curved triangular plate, φ2.6 mm 3-hole mount.
Headstock plate specs
- Overall width 32 mm (1.26 in)
- Bottom width 32 mm (1.26 in)
- Overall length 46.8 mm (1.843 in)
- Hole diameter φ2.6 mm
- Mount spacing 20 mm (0.787 in)
- Reference Base hole pair on 20 mm centers; tip hole center 34.4 mm from base hole line.
Hardware
- Material Plastic plate (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Curved triangular outline 46.8 mm long × 32 mm base
- Countersunk φ2.6 mm holes on 20 mm / 34.4 mm 3-hole layout
About measurements
- Mount hole spacing
-
20 mm (0.787 in)
Center-to-center distance between mounting holes on the bridge plate.
