Truss rod cover
Request a quote → HA-2015
HA-2015
Technical drawingHA-2015
Description
HA-2015 truss rod cover, 42.3 × 26.8 mm teardrop plate, φ2.8 mm 3-hole mount.
Headstock plate specs
- Overall width 26.8 mm (1.055 in)
- Bottom width 26.8 mm (1.055 in)
- Overall length 42.3 mm (1.665 in)
- Hole diameter φ2.8 mm
- Mount spacing 19.3 mm (0.76 in)
- Reference Left-edge hole pair on 19.3 mm centers; tip hole center 34 mm from left edge.
Hardware
- Material Plastic plate (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Teardrop profile 42.3 mm long × 26.8 mm straight left edge
- φ2.8 mm holes on 19.3 mm / 34 mm 3-hole layout
About measurements
- Mount hole spacing
-
19.3 mm (0.76 in)
Center-to-center distance between mounting holes on the bridge plate.
