HZ-37
HZ-37
Loading 3D model…
Loading 3D model…
Description
HZ-37 is tremolo hardware saddle block with 16.5 mm width, 23.0 mm height, and 9.0 mm body depth.
Tremolo hardware specs
- Overall width 16.5 mm (0.65 in)
- Thickness 9 mm (0.354 in)
- Overall height 23 mm (0.906 in)
- Reference Two mounting holes shown (diameter and spacing not dimensioned on drawing).
Hardware
- Material Zinc alloy / steel (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Tapered central string slot opening to a U-shaped pocket on the right face
- V-groove on the top surface with 9.0 mm-thick side profile
About measurements
- Mount hole spacing
-
Two mounting holes shown (diameter and spacing not dimensioned on drawing).
Center-to-center distance between mounting holes on the bridge plate.
