KB-3001
KB-3001
Loading 3D model…
Loading 3D model…
Description
Headless string-lock clamp 41.5 × 23.7 mm, height 10.9 mm; guide holes on 4.8 mm pitch (33.6 mm spread).
Hardware part specs
- Overall width 41.5 mm (1.634 in)
- Overall length 23.7 mm (0.933 in)
- Body height 10.9 mm (0.429 in)
- Mount spacing 33.6 mm (1.323 in)
- Reference Guide holes on 4.8 mm pitch
Hardware
- Material Zinc alloy / steel (per part)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Knurled thumb screw clamp
- Hook-profile body
About measurements
- Mount hole spacing
-
33.6 mm (1.323 in)
Center-to-center distance between mounting holes on the bridge plate.
