Guitar Pickups
Request a quote → P-2013
P-2013
P-2013
Loading 3D model…
Loading 3D model…
Description
P-2013 is a 6-string humbucker pickup with a 68 × 37.3 mm body, 78.5 mm mount spacing, and 50/52/53 mm pole spacing options.
Pickup specs
- String count 6-string
- Overall width 37.3 mm (1.469 in)
- Overall length 84.5 mm (3.327 in)
- Mount spacing 78.5 mm (3.091 in)
- Reference Overall width including tabs 84.5 mm; pole spacing 50, 52, or 53 mm
Hardware
- Material Alnico / ceramic magnets; metal cover or bobbin (per model)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Dual-coil humbucker with 6 pole pieces per coil
- Side mounting tabs with one hole each
- Pole spacing options 50 mm, 52 mm, or 53 mm
About measurements
- Mount hole spacing
-
78.5 mm (3.091 in)
Center-to-center distance between mounting holes on the bridge plate.
