Description
TL-003 tailpiece thumbwheel and post set, M4 × Ø16 knurled wheel (3.4 mm thick) on 20 mm post.
Tailpiece adjuster specs
- Outer diameter φ16 mm
- Thumbwheel thickness 3.4 mm (0.134 in)
- Post height 20 mm (0.787 in)
- Hole diameter φ2.3 mm
- Thread M4
- Reference M4 internal thread, 5 mm depth at post top.
Hardware
- Material Brass / steel (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
About measurements
- Mount hole spacing
-
M4 internal thread, 5 mm depth at post top.
Center-to-center distance between mounting holes on the bridge plate.
