Description
TL-004 tailpiece thumbwheel and post set, M3 × Ø10.3 knurled wheel (2 mm thick) on 16 mm post.
Tailpiece adjuster specs
- Outer diameter φ10.3 mm
- Overall width 1.7 mm (0.067 in)
- Thumbwheel thickness 2 mm (0.079 in)
- Post height 16 mm (0.63 in)
- Thread M3
- Reference Compact M3 set; post width 1.7 mm; 2.5 mm thread depth.
Hardware
- Material Brass / steel (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
About measurements
- Mount hole spacing
-
Compact M3 set; post width 1.7 mm; 2.5 mm thread depth.
Center-to-center distance between mounting holes on the bridge plate.
