Bass Bridges
Request a quote → BA-1001
BA-1001
BA-1001
Loading 3D model…
Loading 3D model…
Description
BA-1001 is a 4-string bass bridge with steel saddles and 19 mm string spacing on an 80 × 43 mm plate. Three-point top mount at 65.2 mm suits common import bass bodies.
Bridge specs
- String count 4-string
- String spacing 19 mm (0.748 in)
- Plate width 80 mm (3.15 in)
- Plate depth 43 mm (1.693 in)
- Mount hole spacing 65.2 mm (2.567 in)
- Mount pattern 3 top holes on 32.6 mm pitch
- Saddle material Steel
- Saddle diameter 19 mm (0.748 in)
- Hole diameter φ8 mm (0.315 in)
Hardware
- Adjustment Height and intonation screws
- Finish More colors — see matching swatches
Features
- Steel barrel saddles
- 19 mm string spacing
- Top-mount hole pattern per drawing
About measurements
- String spacing
-
19 mm (0.748 in)
Center-to-center distance between adjacent strings at the bridge.
- Mount hole spacing
-
65.2 mm (2.567 in)
Center-to-center distance between mounting holes on the bridge plate.
