Description
BA-1003 is a 4-string bass bridge with zinc saddles, 20 mm spacing, and a 93.5 × 45.5 mm plate with three top mount holes.
Bridge specs
- String count 4-string
- String spacing 20 mm (0.787 in)
- Plate width 93.5 mm (3.681 in)
- Plate depth 45.5 mm (1.791 in)
- Mount pattern Top holes at 40 mm and 41.3 mm pitch (asymmetric)
- Saddle material Zinc alloy
- Saddle diameter 17.5 mm (0.689 in)
- Saddle height 18 mm (0.709 in)
Hardware
- Adjustment Height and intonation screws
- Finish More colors — see matching swatches
Features
- Zinc block saddles
- Three-hole top mount
- Individual height screws
About measurements
- String spacing
-
20 mm (0.787 in)
Center-to-center distance between adjacent strings at the bridge.
- Mount hole spacing
-
Top holes at 40 mm and 41.3 mm pitch (asymmetric)
Center-to-center distance between mounting holes on the bridge plate.
