Description
BA-1009 is a 4-string bass bridge with steel saddles, 19 mm spacing, and an 81.2 × 53 mm plate with five top mount holes on 17.5 mm pitch.
Bridge specs
- String count 4-string
- String spacing 19 mm (0.748 in)
- Plate width 81.2 mm (3.197 in)
- Plate depth 53 mm (2.087 in)
- Mount hole spacing 70 mm (2.756 in)
- Mount pattern 5 holes on 17.5 mm pitch (outer centers 70 mm)
- Saddle material Steel
- Saddle diameter 19.2 mm (0.756 in)
- Hole diameter φ9 mm (0.354 in)
Hardware
- Adjustment Height and intonation screws
- Finish More colors — see matching swatches
Features
- Five-hole top mount
- Steel saddles with spring intonation
About measurements
- String spacing
-
19 mm (0.748 in)
Center-to-center distance between adjacent strings at the bridge.
- Mount hole spacing
-
70 mm (2.756 in)
Center-to-center distance between mounting holes on the bridge plate.
