Description
BA-2003 is a compact individual-string bass bridge module, 15.6 mm wide and 71.8 mm long, for custom per-string spacing on modern bass builds.
Bridge specs
- Configuration Individual-string module
- Module length 71.8 mm (2.827 in)
- Module width 15.6 mm (0.614 in)
- Body height 9.3 mm (0.366 in)
- Saddle material Zinc alloy
- Saddle diameter 11.5 mm (0.453 in)
Hardware
- Adjustment Height and intonation screws
- Finish More colors — see matching swatches
Features
- One module per string
- Low 9.3 mm profile height
About measurements
- String spacing
-
15.6 mm (0.614 in)
Center-to-center distance between adjacent strings at the bridge.
- Module layout
-
One bridge module per string; overall spacing is set by body routing.
