Bass Bridges
Request a quote → BA-2012A
BA-2012A
Technical drawingBA-2012A
Description
BA-2012A is a 4-string bass bridge variant with zinc saddles, 17 mm string spacing (51 mm spread), and a 92.1 × 63.3 mm plate.
Bridge specs
- String count 4-string
- String spacing 17 mm (0.669 in)
- String spread 51 mm (2.008 in)
- Plate width 92.1 mm (3.626 in)
- Plate depth 63.3 mm (2.492 in)
- Mount pattern Intonation screw centers on 18.2 mm pitch
- Saddle material Zinc alloy
- Saddle diameter 16.8 mm (0.661 in)
- Saddle height 9.4 mm (0.37 in)
Hardware
- Adjustment Height and intonation screws
- Finish More colors — see matching swatches
Features
- BA-2012 family variant
- Barrel-style block saddles
About measurements
- String spacing
-
17 mm (0.669 in)
Center-to-center distance between adjacent strings at the bridge.
- Mount hole spacing
-
Intonation screw centers on 18.2 mm pitch
Center-to-center distance between mounting holes on the bridge plate.
