Bass Bridges
Request a quote → BA-3001
BA-3001
BA-3001
Loading 3D model…
Loading 3D model…
Description
BA-3001 is a compact individual-string bass bridge module with zinc saddle, 15.6 mm module width, and 71.8 mm overall length. Use one module per string for custom spacing on modern bass builds.
Bridge specs
- Configuration Individual-string module
- Module length 71.8 mm (2.827 in)
- Module width 15.6 mm (0.614 in)
- Body height 9.3 mm (0.366 in)
- Saddle material Zinc alloy
- Saddle diameter 11.5 mm (0.453 in)
Hardware
- Adjustment Height and intonation screws
- Finish More colors — see matching swatches
Features
- One module per string — layout spacing to your body design
- Spring-loaded intonation screw and dual height grub screws
- Zinc saddle with M3 hardware kit
- Suited to compact and multi-scale bass routes
About measurements
- String spacing
-
15.6 mm (0.614 in)
Center-to-center distance between adjacent strings at the bridge.
- Mount hole spacing
-
Body recess 35.0 × 8.0 mm (per drawing)
Center-to-center distance between mounting holes on the bridge plate.
- Module layout
-
One bridge module per string; overall spacing is set by body routing.
