Description
BA-3004 is a 6-string bass bridge with zinc saddles, 10.5 mm string spacing (52.5 mm spread), and an 83 × 38 mm plate.
Bridge specs
- String count 6-string
- String spacing 10.5 mm (0.413 in)
- String spread 52.5 mm (2.067 in)
- Plate width 83 mm (3.268 in)
- Plate depth 38 mm (1.496 in)
- Mount hole spacing 54.5 mm (2.146 in)
- Mount pattern Mount holes 22 / 10.5 / 22 mm pitch (54.5 mm outer)
- Saddle material Zinc alloy
- Saddle diameter 10.5 mm (0.413 in)
- Saddle height 5 mm (0.197 in)
Hardware
- Adjustment Height and intonation screws
- Finish More colors — see matching swatches
Features
- 6-string compact spacing
- 5 mm low saddle height
About measurements
- String spacing
-
10.5 mm (0.413 in)
Center-to-center distance between adjacent strings at the bridge.
- Mount hole spacing
-
54.5 mm (2.146 in)
Center-to-center distance between mounting holes on the bridge plate.
