Description
BG-2006 is a compact 6-string fixed bridge with 10.5 mm spacing on a 74 × 45.9 mm plate and 5.5 mm plate thickness.
Bridge specs
- String count 6-string
- String spacing 10.5 mm (0.413 in)
- Plate width 74 mm (2.913 in)
- Plate depth 45.9 mm (1.807 in)
- Mount pattern Lower saddle row spacing 21.85 mm each side of center
- Saddle material Zinc alloy
- Saddle diameter 10.3 mm (0.406 in)
- Overall height 5.5 mm (0.217 in)
Hardware
- Adjustment Height and intonation screws
- Finish More colors — see matching swatches
Features
- Compact footprint for import bodies
- 10.3 mm saddle width
About measurements
- String spacing
-
10.5 mm (0.413 in)
Center-to-center distance between adjacent strings at the bridge.
- Mount hole spacing
-
Lower saddle row spacing 21.85 mm each side of center
Center-to-center distance between mounting holes on the bridge plate.
