Description
BG-6016 is a 7-string tremolo bridge with 107 × 70.2 mm plate, 15 mm block thickness, and 40.7 mm overall depth.
Tremolo bridge specs
- String count 7-string
- String spacing undefined mm (NaN in)
- Plate width 70.2 mm (2.764 in)
- Plate depth 107 mm (4.213 in)
- Mount pattern Three φ3.7 mm holes on 30 mm pitch
- Saddle material Zinc alloy
- Hole diameter φ3.7 mm (0.146 in)
- Overall height 40.7 mm (1.602 in)
Hardware
- Sustain block height 15 mm (0.591 in)
- Adjustment Height and intonation screws
- Finish More colors — see matching swatches
Features
- 7-string synchronized trem
- Side-mount trem arm
About measurements
- Mount hole spacing
-
Three φ3.7 mm holes on 30 mm pitch
Center-to-center distance between mounting holes on the bridge plate.
- Sustain block
-
15 mm (0.591 in) block height
Tremolo block depth sets spring tension range; verify against body cavity depth.
