Truss rod cover
Request a quote → HA-2050
HA-2050
Technical drawingHA-2050
Description
HA-2050 truss rod cover, 42 × 25 mm teardrop plate, φ2.6 mm 3-hole mount.
Headstock plate specs
- Overall width 25 mm (0.984 in)
- Bottom width 25 mm (0.984 in)
- Overall length 42 mm (1.654 in)
- Hole diameter φ2.6 mm
- Mount spacing 16 mm (0.63 in)
- Reference Left hole pair on 16 mm centers; tip hole center 34 mm from left hole line; countersunk outer φ4.5 mm.
Hardware
- Material Plastic plate (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Teardrop profile 42 mm long × 25 mm flat left edge
- φ2.6 mm through-holes with φ4.5 mm countersink on 16 mm / 34 mm 3-hole layout
About measurements
- Mount hole spacing
-
16 mm (0.63 in)
Center-to-center distance between mounting holes on the bridge plate.
