Request a quote → HJ-1010
HJ-1010
HJ-1010
Loading 3D model…
Loading 3D model…
Description
HJ-1010 Flying V string-through plate, 160 × 86.8 mm with six φ3 mm string holes and φ3.3 mm mount holes.
Control plate specs
- Overall width 160 mm (6.299 in)
- Overall length 86.8 mm (3.417 in)
- Hole diameter φ3 mm
- Reference Inner V height 52.1 mm; outer wing edge 83 mm; three countersunk mount holes.
Hardware
- Material Plastic / metal plate (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
About measurements
- Mount hole spacing
-
Inner V height 52.1 mm; outer wing edge 83 mm; three countersunk mount holes.
Center-to-center distance between mounting holes on the bridge plate.
