HJ-1014B
Technical drawingHJ-1014B
Description
HJ-1014B Jazz Bass-style plate, 128.53 × 67.25 mm with two φ8 mm and one φ10 mm control holes.
Control plate specs
- Overall width 128.53 mm (5.06 in)
- Overall length 67.25 mm (2.648 in)
- Hole diameter φ8 mm
- Reference Left-side mount holes on 47.24 mm vertical centers; tip mount at rounded end.
Hardware
- Material Plastic / metal plate (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
About measurements
- Mount hole spacing
-
Left-side mount holes on 47.24 mm vertical centers; tip mount at rounded end.
Center-to-center distance between mounting holes on the bridge plate.
