Bass Pickups
Request a quote → PB-2001
PB-2001
PB-2001
Loading 3D model…
Loading 3D model…
Description
PB-2001 Jazz Bass pickup, 91–94 × 18.2 mm body, 28.6 mm overall width, 38–40 mm mount spacing.
Pickup specs
- Overall width 18.2 mm (0.717 in)
- Overall length 93 mm (3.661 in)
- Mount spacing 39 mm (1.535 in)
- Reference Body length range 91–94 mm; mount spacing range 38–40 mm; four mounting tabs.
Hardware
- Material Alnico / ceramic magnets; metal cover or bobbin (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
About measurements
- Mount hole spacing
-
39 mm (1.535 in)
Center-to-center distance between mounting holes on the bridge plate.
