Bass Pickups
Request a quote → PB-2004
PB-2004
PB-2004
Loading 3D model…
Loading 3D model…
Description
PB-2004 Jazz Bass pickup, 91–94 × 18.2 mm body with eight pole pieces on 72.2–74.5 mm spread.
Pickup specs
- String count 4-string
- String spread 73.4 mm (2.89 in)
- Overall width 18.2 mm (0.717 in)
- Overall length 93 mm (3.661 in)
- Mount spacing 39 mm (1.535 in)
- Reference Bridge-position pole spread 72.2–74.5 mm; mount spacing 38–40 mm.
Hardware
- Material Alnico / ceramic magnets; metal cover or bobbin (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
About measurements
- Mount hole spacing
-
39 mm (1.535 in)
Center-to-center distance between mounting holes on the bridge plate.
