Request a quote → BA-3006
BA-3006
BA-3006
Loading 3D model…
Loading 3D model…
Description
BA-3006 is a 4-string bass bridge with zinc saddles, 10.8 mm saddle width, and an 85.7 × 37 mm plate with asymmetric top mount.
Bridge specs
- String count 4-string
- String spacing 10.8 mm (0.425 in)
- String spread 32.4 mm (1.276 in)
- Plate width 85.7 mm (3.374 in)
- Plate depth 37 mm (1.457 in)
- Mount hole spacing 75.5 mm (2.972 in)
- Mount pattern Top holes 21.5 / 32.5 / 21.5 mm pitch
- Saddle material Zinc alloy
- Saddle diameter 10.8 mm (0.425 in)
- Saddle height 5.5 mm (0.217 in)
Hardware
- Adjustment Height and intonation screws
- Finish More colors — see matching swatches
Features
- Asymmetric mount pattern
- Teardrop string grooves
About measurements
- String spacing
-
10.8 mm (0.425 in)
Center-to-center distance between adjacent strings at the bridge.
- Mount hole spacing
-
75.5 mm (2.972 in)
Center-to-center distance between mounting holes on the bridge plate.
