Description
F-1011 output jack plate, 81 × 32.4 mm recessed oval boat plate with 15.6 mm profile height and 71 mm two-hole mount spacing.
Output jack plate specs
- Overall width 81 mm (3.189 in)
- Overall length 32.4 mm (1.276 in)
- Plate thickness 15.6 mm (0.614 in)
- Mount spacing 71 mm (2.795 in)
- Reference Two φ4.8 mm end mounting holes on 71 mm centers; jack bore diameter not dimensioned on drawing.
Hardware
- Material Plastic / metal (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Recessed oval boat profile with curved body-contour fit
- Two φ4.8 mm end mounting holes on 71 mm centers
About measurements
- Mount hole spacing
-
71 mm (2.795 in)
Center-to-center distance between mounting holes on the bridge plate.
