PICKGUARDS
Request a quote → H-3004
H-3004
Technical drawingH-3004
Description
Pickguard 100.1 × 208.7 mm with 61.3 mm pickup cutout, 6 × Φ3.2 mm mounting holes.
Pickguard specs
- Overall width 100.1 mm (3.941 in)
- Overall length 208.7 mm (8.217 in)
- Mount hole diameter φ3.2 mm
- Layout reference 6 mounting holes.
Hardware
- Material PVC / ABS plastic (standard)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Neck pickup cutout 61.3 mm high
- beveled edge.
About measurements
- Mount hole spacing
-
6 mounting holes.
Center-to-center distance between mounting holes on the bridge plate.
