Description
Bridge assembly 42 × 22.8 mm, body height 8 mm, overall height 22 mm, Φ3 holes, 28.4 mm spacing.
Hardware part specs
- Overall width 42 mm (1.654 in)
- Overall length 22.8 mm (0.898 in)
- Body height 8 mm (0.315 in)
- Overall height 22 mm (0.866 in)
- Hole diameter φ3 mm
- Mount spacing 28.4 mm (1.118 in)
- Reference 35.5 mm spread (7.1×5 pattern); base depth 18.5 mm
Hardware
- Material Zinc alloy / steel (per part)
- Adjustment N/A
- Finish More colors — see matching swatches
Features
- Multi-hole bridge base
About measurements
- Mount hole spacing
-
28.4 mm (1.118 in)
Center-to-center distance between mounting holes on the bridge plate.
